Item | Parameter | ||
Optical output power (mW) | 2~10 | ||
Wavelength (nm) | 1310, 1550 option | ||
Optical connector | FC/APC, SC/APC, SC/PC, LC/APC, ,LC/PC option | ||
Working bandwidth (MHz) | 47~2600 | ||
CNR (dB) | ≥51 | 42CH CENELEC 80dBuV AGC OMI=3.8% | |
CTB (dB) | ≥63 | ||
CSO (dB) | ≥58 | ||
Input level (dBµV) | 80±5 | ||
Flatness (dB) | 47~950MHz | ≤±0.75 | |
950~2600MHz | ≤±1.00 | ||
Power consumption (W) | ≤30 | ||
Power supply (V) | 220VAC, -48VDC option | ||
Working temp (℃) | -20~85 | ||
Size (mm) | 350×200×45 | ||
Weight (Kg) | 3.0 | ||
Adopt low noise imported DFB laser.
Superior pre-distortion circuit design, in achieving high standards of CNR value, there are still perfect CTB and CSO performance value.
Intelligent fan, it began to run when the chassis temperature reaches the set 32 ~ 35 ℃.
AGC control, so that different RF input level can still maintain a considerable output performance.
VFD or LED display, with laser monitoring, digital display, fault alarm, network management and other functions; once the laser operating parameters deviate from the software set the allowable range, will alert.
With standard RS232 interface for local network management and monitoring of computers.
With standard RJ45 interface support SNMP for remote monitoring.
High-quality switching power supply 90V ~ 265V AC
Single input with frequency 47～2600MHz.
Prepare before installation
Check if the equipment is noticeably damaged.
Check all accessories are available, whether the certificate is complete, if damaged or missing parts of the situation, according to the return process.
Installation
In the installation of multiple devices, up and down between at least 1.75 inches (about 4.5cm) of space, in order to facilitate the ventilation and heat dissipation.
Check that the power outlet and grounding will be used properly, grounding resistance should be ≤4Ω, improper grounding may damage the device or lead to poor signal quality.
Before connecting the power cord, make sure that the power switch on the rear panel is in the OFF position.
Connect RF signal with coaxial cable.
Connect the external fiber, the fiber must be cleaned before the connection, fiber optic connector can choose FC / APC or SC / APC form.
