| Material | Size | Max Capacity | Reinforced Adaptor | Color | |
| Strengthen Polymer Plastic | L*W*H(mm) 385*245*150 | Splice 144 Fibers (6trays,24 fiber/tray) | PLC Splitter 1pcs of 1x16 | 16pcs SC/UPC or SC/APC | Black |
Water-proof design with IP-68 Protection level.
Integrated with flap-up splice trays.
Impact test:IK10,Pull Force:100N,Full rugged design.
Maximum 144F splice capacity, stainless anti-rust bolts and nuts.
Plug-and-play installation, easy for maintenance and expansion.
Fiber bend radius control more than 40mm.
180 degree access with buckled lock structure.
1*16 PLC Splitter can be installed in each splice tray as option.
Mechanical sealing structure and mid-span cable entry.
16 pcs of pre-installed reinforced water-proof adapter for SC.
1 mid-span cable entrance(10-16.5mm) for uncut cable and 2 mechanicals glands for distribution cable (8-16.5mm).
