Fiber Optic Patch Cord

How to Choose the Appropriate Fiber Optic Patch Cord?

Choosing the right fiber optic patch cord is crucial for optimal network performance. Consider these factors:

1. Fiber Type: Select single-mode or multimode based on your network's requirements for distance and bandwidth.

2. Connector Type: Match connector types (e.g., LC, SC) with your network equipment to ensure compatibility.

3. Length: Choose an appropriate length to reach from one device to another without excess slack.

4. Environment: For harsh environments, opt for armored patch cords, while indoor environments may use standard patch cords with PVC or LSZH jackets.

Features of the Fiber Optic Patch Cord

Fiber optic patch cords come in various types and configurations, but here are four common features found in these essential components of optical communication networks:

1. Fiber Type:

Fiber optic patch cords can be made with different types of optical fibers, such as single-mode (SM) or multimode (MM). The choice of fiber type depends on the specific network requirements, including transmission distance and bandwidth.

2. Connector Types:

Patch cords are available with a variety of connectors at each end, including SC, LC, ST, MTP/MPO, and more. The selection of connector types should match the connectors used on the network equipment to ensure proper connectivity.

3. Jacket Material:

The outer jacket of a fiber optic patch cord is typically made of materials like PVC (Polyvinyl Chloride) or LSZH (Low Smoke Zero Halogen). The jacket material affects the cable's flexibility, flame resistance, and suitability for different environments, such as plenum spaces.

4. Cable Length:

Fiber optic patch cords come in various standard lengths, such as 1 meter, 2 meters, and longer. Choosing the right cable length is essential to ensure that the patch cord reaches from one network component to another without excess slack or tension, which can impact performance.
